Model JLN-205 Pulse Doppler Sensing Dual Beam 2MHz Speed Log Power consumption High Accuracy Cost-effective

    Buy cheap Model JLN-205 Pulse Doppler Sensing Dual Beam 2MHz Speed Log Power consumption High Accuracy Cost-effective from wholesalers

    Buy cheap Model JLN-205 Pulse Doppler Sensing Dual Beam 2MHz Speed Log Power consumption High Accuracy Cost-effective from wholesalers
    • Buy cheap Model JLN-205 Pulse Doppler Sensing Dual Beam 2MHz Speed Log Power consumption High Accuracy Cost-effective from wholesalers

    Model JLN-205 Pulse Doppler Sensing Dual Beam 2MHz Speed Log Power consumption High Accuracy Cost-effective

    Ask Lasest Price
    Brand Name : JRC
    Model Number : JLN-205
    Certification : CCS
    Payment Terms : L/C, T/T
    Supply Ability : 30 set per month
    Delivery Time : 15 Days
    • Product Details
    • Company Profile

    Model JLN-205 Pulse Doppler Sensing Dual Beam 2MHz Speed Log Power consumption High Accuracy Cost-effective

    Model JLN-205 Pulse Doppler Sensing Dual Beam 2MHz Speed Log Power consumption High Accuracy Cost-effective


    Model JLN-205 Pulse Doppler Sensing Dual Beam 2MHz Speed Log Power consumption High Accuracy Cost-effective


    Specifications

    Operating MethodDual beam, pulse Doppler sensing.
    Frequency2MHz
    Speed range-10.0 to +40.0 knot
    Distance run range0 to 99999.99nm *Note: NWW-7 optional indicator allows the range from 0 to 9999.99 nm
    Depth range3m or more (below hull bottom)
    Accuracy+/-1% or +/-0.1 knot whichever is greater
    +/-1% or +/-0.1 nm whichever is greater
    IndictionDigital indicator.
    Analog indicator (where using option unit of NWW-24/25/26)
    IEC61162-1 inputRMC, RMA or VTG (for SOG indication from GPS receiver)
    IEC61162-1 Output8 port/$VDVBW, $VDVLW sentence
    Other Outputsfor Analoge indicator: 2 circuits / Pulse for distance-run : 4 circuits /.
    Contact closure: 1 circuit / for Sub display: 2 circuits / for Distance-run indicator: 1 circuit /
    for Remote display: 1 circuit / for Remote diagnostic data port: 1 circuit / .
    for power fail: 1 circuit
    Power supply100 / 110 / 115 / 220 / 230 Vac +/- 10%, 50/60Hz, 1-phase
    Power consumption100VA or less
    Operating temperature-15 to +55 deg. C

    Standard Components

    No.NAMETYPEQ'TYREMARKS
    1Main DisplayNWW-651Desktop, (Flush mounting kit:option), with a cable of 5m length.
    2Data DistributorNQA-42881
    3Signal ProcessorNJC-251IP×5
    4TransducerNKF-5471With a cable of 30m length
    5Spare Parts7ZXBS00201
    6Instruction Manual7ZPBS2803

    Option Components

    No.NAMETYPEQ'TYREMARKS
    1Sub DisplayNWW-65SMax. 2
    2Analog IndicatorNWW-24Max. 2.Flush mouting
    3NWW-25Bulkhead mounting / Waterproof
    4NWW-26Panel mounting
    5Remote IndicatorNWW-5.Max. 1Ship's speed (fore / aft)
    6Remote IndicatorNWW-16Ship's
    speed(fore/aft)/Distance-
    run/Indication
    range:9999.99nm
    7Distance-run IndicatorNWW-7.Max. 1Distance-run/Indication
    range:9999.99nm
    8Dimmer UnitNCM-227DFor main / sub display
    9NCM-329For analog indicator
    10NCM-227For remote indicator
    11Connection BoxNQD-20251for extension between
    NWW-65 and NQA-4288
    12Transducer (Gate-valve type)NKF-531E1With a cable of 25m length
    13Flush mounting kitMPTG30432for Main/Sub Display
